Screw Air Compressor( fixed/variable frequency) – JN Series

Features

IEC high-efficiency drive motor.

IP54 and high temperature F class protection grade.

High exhaust temperature shutdown.

Automatic dual control.

Overload start protection.

Easy to use and maintenance free.

Product Details

JN Series - low voltage Parameters

Model Exhaust  pressure(Mpa) Exhaust volume (m³/min) Motor power (KW) Exhaust  connection Weight (kg) Dimension (mm)
JN37-3N 0.3 10.7 37 DN65 880 1780x940x1435
JN37-3G 10.7 37 DN65 950 1695x1050x1590
JN55-3G 18.2 55 DN100 2070 2510x1560x1860
JN55-3GA 19.5 55 DN100 2330 2510x1560x1860
KHE90-3GA 30.4 90 DN125 3900 2860x1760x2050
KHE132-3A 43.8 132 DN125 6500 3560x2160x2200
KHE160-3GA 52.9 160 DN150 5000 3280x2060x2240
KHE250-3GA 80.5 250 DN150 8500 4390x2200x2360

JN Series - high pressure Parameters

Model Exhaust  pressure(Mpa) Exhaust volume (m³/min) Motor power (KW) Exhaust  connection Weight (kg) Dimension (mm)
JN200W-25 2.5 20 200 DN65 5300 3440x1860x2230
JN200W-35 3.5 16 200 DN65 5300 3440x1860x2230
JN250W-25 2.5 26 250 DN65 6100 3440x1860x2230
JN250W-35 3.5 21 250 DN65 6100 3440x1860x2230
JN315W-25 2.5 31 315 DN80 6500 3760x2260x2260
JN315W-35 3.5 26 315 DN80 6500 3760x2260x2260
JN400W-25 2.5 39 400 DN80 7400 3760x2260x2260
JN400W-35 3.5 32 400 DN80 7400 3760x2260x2260

PMVF low voltage series Parameters

Model Exhaust  pressure(Mpa) Exhaust volume (m³/min) Motor power (KW) Exhaust  connection Weight (kg) Dimension (mm)
PMVFF55-2.5 0.25 21.5 55 DN100 1820 2150x1560x1860
PMVF55-1.5 0.15 28.5 55 DN150 3450 2660x2020x2140
PMVF75-2.5 0.25 28.5 75 DN150 3500 2660x2020x2140
PMVF90-2.5 0.25 36.5 90 DN150 3550 2660x2020x2140
PMVF110-1.5 0.15 51.5 110 DN250 6050 4110x2140x2280
PMVF132-2.5 0.25 51.5 132 DN250 6110 4110x2140x2280
PMVF160-2.5 0.25 60 160 DN250 6200 4110x2140x2280
PMVF37-3G 0.3 10.7 37 DN65 950 1695x1050x1590
PMVF55-3G 0.3 18.2 55 DN100 2070 2510x1560x1860
PMVF55-3GA 0.3 19.5 55 DN100 2330 2510x1560x1860
PMVF75-3GA 0.3 25.3 75 DN125 3850 2860x1760x2050
PMVF90-3GA 0.3 30.4 90 DN125 3900 2860x1760x2050
PMVF132-3GA 0.3 44.5 132 DN150 4600 3280x2060x2240
PMVF160-3GA 0.3 52.9 160 DN150 5000 3280x2060x2240
PMVF185-3GA 0.3 61.2 185 DN200 6300 4280x2100x2300
PMVF200-3GA 0.3 66 200 DN200 6500 4280x2100x2300
PMVF250-3GA 0.3 80.5 250 DN250 8500 4390x2200x2350

JN Series - two-stage compression electric solid Parameters

Model Exhaust  pressure(Mpa) Exhaust volume (m³/min) Motor power (KW) Exhaust  connection Weight (kg) Dimension (mm)
JN100-6-II 0.6 16.55 75 DN65 2200 2760x1630x1735
JN100-7-II 0.7 15.8 75 DN65 2200 2760x1630x1735
JN100-8-II 0.8 14.65 75 DN65 2200 2760x1630x1735
JN100-10-II 1 13.7 75 DN65 2200 2760x1630x1735
JN120-6-II 0.6 21.68 90 DN80 2720 2760x1630x1735
JN120-7-II 0.7 20.15 90 DN80 2720 2760x1630x1735
JN120-8-II 0.8 19.25 90 DN65 2700 2760x1630x1735
JN120-10-II 1 16.48 90 DN65 2700 2760x1630x1735
JN150-6-II 0.6 25.54 110 DN80 3300 2930x1810x1800
JN150-7-II 0.7 24.02 110 DN80 3300 2930x1810x1800
JN150-8-II 0.8 23 110 DN80 3300 2930x1810x1800
JN150-10-II 1 20.1 110 DN80 3300 2930x1810x1800
JN180-6-II 0.6 32.88 132 DN100 4380 3160x1810x2080
JN180-7-II 0.7 28.55 132 DN100 3560 2930x1810x2080
JN180-8-II 0.8 26.9 132 DN80 3460 2930x1810x1800
JN180-10-II 1 23.94 132 DN80 3460 2930x1810x1800
JN215-6-II 0.6 38.07 160 DN100 4900 3310x1980x2100
JN215-7-II 0.7 36.6 160 DN100 4900 3310x1980x2100
JN215-8-II 0.8 34.31 160 DN100 4900 3310x1980x2100
JN215-10-II 1 28.46 160 DN100 4900 3310x1980x2100
JN250-6-II 0.6 45.26 185 DN100 5040 3310x1980x2230
JN250-7-II 0.7 41.1 185 DN100 4950 3310x1980x2100
JN250-8-II 0.8 39.8 185 DN100 4950 3310x1980x2100
JN250-10-II 1 34.31 185 DN100 4950 3310x1980x2100
JN270-6-II 0.6 47.9 200 DN100 5050 3310x1980x2230
JN270-7-II 0.7 45.28 200 DN100 5050 3310x1980x2230
JN270-8-II 0.8 43.12 200 DN100 5000 3310x1980x2100
JN270-10-II 1 36.6 200 DN100 5000 3310x1980x2100
JN295-6-II 0.6 55.9 220 DN100 6350 3510x2160x2250
JN295-7-II 0.7 50.26 220 DN100 6350 3510x2160x2250
JN295-8-II 0.8 47.48 220 DN100 5680 3510x2160x2250
JN295-10-II 1 41.02 220 DN100 5680 3510x2160x2250
JN335-6-II 0.6 59.7 250 DN125 6930 3510x2160x2250
JN335-7-II 0.7 56 250 DN125 6930 3510x2160x2250
JN335-8-II 0.8 52.5 250 DN100 6550 3510x2160x2250
JN335-10-II 1 45 250 DN100 6550 3510x2160x2250
JN375-6-II 0.6 64.8 280 DN125 7260 4110x2310x2350
JN375-7-II 0.7 62.4 280 DN125 7260 4110x2310x2350
JN375-8-II 0.8 59.5 280 DN125 7260 4110x2310x2350
JN375-10-II 1 55.7 280 DN125 7260 4110x2310x2350
JN420-6-II 0.6 73.3 315 DN125 8460 4110x2370x2525
JN420-7-II 0.7 66.7 315 DN125 8460 4110x2370x2525
JN420-8-II 0.8 64.8 315 DN125 7360 4110x2310x2350
JN420-10-II 1 59.01 315 DN125 7360 4110x2310x2350
JN475-6A-II 0.6 77 355 DN125 8560 4110x2370x2525
JN475-7A-II 0.7 73.2 355 DN125 8560 4110x2370x2525
JN475-8A-II 0.8 69.9 355 DN125 7460 4110x2310x2350
JN475-10A-II 1 62.1 355 DN125 7460 4110x2310x2350

Applications

Mechanical

Metallurgy

Electronic Power

Medicine

Packing

Chemical Industry

Food

Textile
