| Model | Exhaust pressure(Mpa) |
Exhaust volume (m³/min) |
Motor power (KW) |
Exhaust connection |
Weight (kg) |
Dimension (mm) |
| BK7.5-8G | 0.8 | 1.2 | 7.5 | G3/4 | 200 | 800x620x800 |
| BK7.5G-8 | 0.8 | 1.1 | 7.5 | G3/4 | 200 | 880x510x800 |
| BK11-8G | 0.8 | 1.7 | 11 | G1 | 280 | 1000x670x1090 |
| BK15-8G | 0.8 | 2.4 | 15 | G1 | 280 | 1000x670x1090 |
| BK15-8 | 0.8 | 2.4 | 15 | G1 | 270 | 700x670x1250 |
| BK15-10 | 1 | 2.2 | 15 | G1 | 270 | 700x670x1250 |
| BK15-13 | 1.3 | 1.7 | 15 | G1 | 270 | 700x670x1250 |
| BK22-8G | 0.8 | 3.45 | 22 | G1 | 390 | 1200x800x1120 |
| BK22-10G | 1 | 3.2 | 22 | G1 | 390 | 1200x800x1120 |
| BK22-13G | 1.3 | 2.7 | 22 | G1 | 390 | 1200x800x1120 |
| BK30-8G | 0.8 | 5 | 30 | G1½ | 470 | 1340x850x1330 |
| BK30-10G | 1 | 4.4 | 30 | G1½ | 470 | 1340x850x1330 |
| BK30-13G | 1.3 | 3.6 | 30 | G1½ | 470 | 1340x850x1330 |
| BK37-8G | 0.8 | 6 | 37 | G1½ | 560 | 1340x850x1330 |
| BK37-10G | 1 | 5.4 | 37 | G1½ | 560 | 1340x850x1330 |
| BK37-13G | 1.3 | 4.6 | 37 | G1½ | 560 | 1340x850x1330 |
| BK45-8G | 0.8 | 7.1 | 45 | G1½ | 720 | 1480x1030x1340 |
| BK45-10G | 1 | 6.2 | 45 | G1½ | 720 | 1480x1030x1340 |
| BK45-13G | 1.3 | 5.6 | 45 | G1½ | 720 | 1480x1030x1340 |
| BK55-8G | 0.8 | 10 | 55 | G1½ | 790 | 1480x1030x1340 |
| BK55-10G | 1 | 7.2 | 55 | G1½ | 790 | 1480x1030x1340 |
| BK55-13G | 1.3 | 6.2 | 55 | G1½ | 790 | 1480x1030x1340 |
| BK75-8 | 0.8 | 13 | 75 | G2 | 1200 | 1800x1190x1710 |
| BK90-8 | 0.8 | 16 | 90 | G2 | 1240 | 1800x1190x1710 |
| BK110T-8 | 0.8 | 21 | 110 | DN65 | 1630 | 2100x1230x1730 |
| BK110-8 | 0.8 | 21 | 110 | DN65 | 1680 | 2100x1230x1730 |
| BK132T-8 | 0.8 | 24 | 132 | DN65 | 1670 | 2100x1230x1730 |
| BK132-8 | 0.8 | 24 | 132 | DN65 | 1750 | 2100x1230x1730 |
| KS175A-8F | 0.8 | 24 | 132 | DN65 | 1470 | 1800x1230x1670 |
| KS150-8-Ⅱ | 0.8 | 22 | 110 | DN65 | 1950 | 2100x1230x1730 |
| KS175-8-Ⅱ | 0.8 | 25 | 132 | DN65 | 1990 | 2100x1230x1730 |
| Model | Exhaust pressure(Mpa) |
Exhaust volume (m³/min) |
Motor power (KW) |
Exhaust connection |
Weight (kg) |
Dimension (mm) |
| BMVF7.5 | 0.65-1.0 | 1.00-1.25 | 7.5 | G¾ | 170 | 880x510x800 |
| BMVF11 | 0.65-1.0 | 1.50-1.85 | 11 | G1 | 220 | 1000x670x1090 |
| BMVF15 | 0.65-1.0 | 2.05-2.35 | 15 | G1 | 250 | 1000x670x1090 |
| BMVF22 | 0.65-1.0 | 2.95-3.95 | 22 | G1 | 330 | 1200x800x1120 |
| BMVF37 | 0.65-1.0 | 5.05-6.35 | 37 | G1½ | 500 | 1340x850x1330 |
| BMVF45 | 0.65-1.0 | 6.45-8.20 | 45 | G1 ½ | 660 | 1480x1030x1365 |
| BMVF55 | 0.65-1.0 | 8.20-9.85 | 55 | G1 ½ | 710 | 1480x1030x1365 |
| BMVF75 | 0.65-1.0 | 10.50-13.10 | 75 | G2 | 1170 | 1800x1190x1710 |
| BMVF90 | 0.65-1.0 | 12.50-15.50 | 90 | G2 | 1180 | 1800x1190x1710 |
| BMVF110 | 0.65-0.8 | 22 | 110 | DN65 | 1770 | 2700x1230x1730 |
| BMVF132 | 0.65-0.8 | 24 | 132 | DN65 | 1860 | 2700x1230x1730 |
