| Transport dimensions (L × W × H) | 8850*2180*2830mm |
| Weight | 13800kg |
| Rock hardness | f=6-20 |
| Drilling diameter | Φ90-105mm |
| Ground clearance | 430mm |
| Leveling angle of frame | ±10 ° |
| Travelling speed | 0-3 Km/h |
| Climbing capacity | 25° |
| Traction | 120KN |
| Rotary torque（Max） | 1680N.m（Max） |
| Rotation speed | 0-120rpm |
| Lifting angle of drill boom | Up 47 °,down 20 ° |
| Swing angle of drill boom | Left 20 °, right 50 ° |
| Swing angle of carriage | Left 35 °, right 95 ° |
| Tilt angle of beam | 120° |
| Compensation stroke | 1200mm |
| Rotation Head stroke | 3490mm |
| Maximum propelling force | 25KN |
| Method of propulsion | Motor+roller chain |
| Depth of economical drilling | 24m |
| Number of rods | 7＋1 |
| Specifications of drilling rod | Φ64*3000mm |
| DTH hammer | M30 |
| Engine | Yuchai YCA07240-T300 |
| Rated power | 176KW |
| Rated revolving speed | 2200r/min |
| Screw air compressor | Zhejiang Kaishan |
| Capacity | 12m³/min |
| Discharge pressure | 15Bar |
| Traveling control system | Hydraulic pilot |
| Drilling control system | Hydraulic pilot |
| Anti-Jamming | Automatic electro-hydraulic anti-jamming |
| Voltage | 24 V DC |
| Safe cab | Meet the requirements of FOPS & ROPS |
| Indoor noise | Below 85dB（A) |
| Seat | Adjustable |
| Air-conditioning | Standard temperature |
| Entertainment | Radio |
