| Drilling hardness | f=6-20 |
| Drilling diameter | Φ80-105mm |
| Depth of economical drilling | 25m |
| Travelling speed | 2.5/4.0Km/h |
| Climbing capacity | 30° |
| Ground clearance | 430mm |
| Power of complete machine | 162kW |
| Diesel engine | Yuchai YC6J220-T303 |
| Capacity of screw compressor | 12m³/min |
| Discharge pressure of screw compressor |
15bar |
| Outer dimensions (L × W × H) | 7800*2300*2500mm |
| Weight | 8000kg |
| Rotation speed of gyrator | 0-120r/min |
| Rotary torque（Max） | 1680N.m（Max） |
| Maximum push-pull force | 25000N |
| Lifting angle of drill boom | Up54°, down 26° |
| Tilt angle of beam | 125° |
| Swing angle of carriage | Right 47°,left 47° |
| Lateral horizontal swing angle of carriage |
Right-15° ~ 97° |
| Swing angle of drill boom | Right 53°,left 15° |
| Leveling angle of frame | Up 10°, down 9° |
| One-time advance length | 3000mm |
| Compensation length | 900min |
| DTH hammer | M30 |
| Drilling rod | Φ64*3000mm |
| Method of dust collecting | Dry type (hydraulic cyclonic laminar flow) |
