| Drilling hardness | f=6-20 |
| Drilling diameter | Φ135-190mm |
| Depth of economical drilling (depth of automatic extension rod) |
35m |
| Travelling speed | 3.0Km/h |
| Climbing capacity | 25° |
| Ground clearance | 430mm |
| Power of complete machine | 298kW |
| Diesel engine | Cummins QSZ13-C400 |
| Displacement of screw compressor | 22m³/min |
| Discharge pressure of screw compressor |
24bar |
| Outer dimensions (L × W × H) | 11500*2716*3540mm |
| Weight | 23000kg |
| Revolving speed of gyrator | 0-118r/min |
| Rotary torque | 4100N.m |
| Maximum Feed force | 65000N |
| Tilt angle of beam | 125° |
| Swing angle of carriage | Right 97°, left 33° |
| Swing angle of drill boom | Right 42°, left 15° |
| Leveling angle of frame | Up 10°, down 10° |
| Compensation length | 1800mm |
| DTH hammer | K5、K6 |
| Drilling rod (Φ×length of drilling rod) | Φ89*5000mm/Φ102*5000mm |
| Method of dust removal | Dry (hydraulic cyclonic laminar flow)/wet (optional) |
| Method of extension rod | Automatic unloading rod |
| Method of automatic anti-jamming | Electro-hydraulic control anti-sticking |
| Method of drilling rod lubrication | Automatic oil injection and lubrication |
| Protection of thread of drilling rod | Equipped with the floating joint to protect the thread of drilling rod |
| Drilling display | Real-time display of drilling angle and depth |
